Nokia XS-2426G-B User Manual

9.4.1 Configuring an ONT using a configuration file via legacy method
1
Upload the ABCXXXXVER TAR file to the /ONT/ directory in the OLT.
A maximum of 250 files can be kept in the OLT file system.
2
Using OLT commands, download the TAR file to the ONT.
For OLT commands, refer to the , or the 7342 ISAM FTTU Operation and Maintenance Using
TL1 and CLI.
Please note:
• pri-cfgfile-pland/dnload or sec-cfgfile-pland/dnload can be 1 to 14 characters.
• pri-cfgfile-pland and pri-cfgfile-dnload should be the same name.
Examples
Note: X can be 1 or 2 unless specified:
a. If pland-cfgfileX= Disabled and dnload-cfgfileX= Disabled ,
no file will be downloaded to the ONT.
b. If pland-cfgfileX=FILENAME1 and dnload-cfgfileX= Disabled ,
FILENAME1 will be downloaded and FILENAME1 will be made active. An ONT reboot is
required.
c. If pland-cfgfileX=Disabled and dnload-cfgfileX= FILENAME2
FILENAME2 will be downloaded and FILENAME2 will be made passive. An ONT reboot is
not required.
d. If pland-cfgfileX=FILENAME3 and dnload-cfgfileX= FILENAME 4, the OLT reports an
error because the filenames are not the same.
e. Configure equipment interface pland-cfgfile1=XMLXXXXXX1 and dnload-cfgfile1
XMLXXXXXX1
Configure equipment interface pland-cfgfile2=XMLXXXXXX2 and dnload-cfgfile2
XMLXXXXXX2
Although the OLT permits the above two steps without reporting an error, Nokia does not
recommend executing them, because the ONT may exhibit unexpected behavior.
f. If pland-cfgfileX=Auto and dnload-cfgfileX= Auto
The OLT will download the XML file from "sw-ctr-list" (configure equipment ont sw-ctrl)
END OF STEPS
The ONT will distribute the configuration files to the different services based on the active indication
from the OLT and on the Nokia defined index.
The ONT automatically reboots to apply the configuration files. After the ONT reboots and reports
the active version, the OLT completes the file download procedure.
ONT configuration file over OMCI
ONT configuration file over OMCI
Nokia ONT
Review Review
© 2021 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-49546-AAAA-TCZZA
December 2021
150 Issue 1

Nokia XS-2426G-B Specifications

General

GPON Ports	1
Gigabit Ethernet Ports	4
FXS Ports	2
Power over Ethernet	No
VLAN Support	Yes
Jumbo Frame Support	Yes
Operating Temperature	0°C to 40°C
Humidity	5% to 95% (non-condensing)
Wi-Fi Bands	2.4GHz & 5GHz
Management	TR-069
Power Supply	12 V DC
