1
5
1.3
1.4
1.5
STANDARD
Fig. 5
DETAIL OF THE BONDING BETWEEN DIAPHRAGM AND METALLIC SUPPORT
DIAPHRAGM SECTIONAL VIEW
RUBBER
METALLIC
SUPPORT
PFTE
RUBBER
PFTE
NYLON NET
Sectional view without
plastic support ring.
Complete sectional view with
plastic support ring.
GAMAR MOTOR SPECIAL FLANGE AND SHAFT
PUMP TYPE PHASES kW POLES
SIZE
VOLT Hz
MB THREEPH 0,20 4 63
230
50/60
400
MC THREEPH 0,30 4 63
230
50/60
400
0,24/037 4 63/71 230 50
MB
SINGLEPH
0,24/037 4 63/71 230 60
MC 0,24/037 4 63/71 110 50
0,24/037 4 63/71 110 60
Table B
• The OBL's unique (patented) mechanical diaphragm
design ensures controlled volumetric displacement, giving
plunger-like performances.
Thus the flow rate is virtually unaffected by the working
pressure variations.
DIAPHRAGM STRUCTURE
• In table B are described motors installed on MB/MC pumps.
Endless screw is directly keyed on extended motor shaft.
MOTOR CHARACTERISTICS ACCORDING TO THE PUMP SIZE
• The adjustment of the diaphragm stroke is stepless and regular, and can be
carried out any time, i.e. when the pump stands still or is running (fig.5).
FLOW RATE MANUAL BY MICROMETER
GENERAL CHARACTERISTICS
MANUAL ADJUSTMENT
