OBL MB Series User Manual

2
7
➜
➜
➜ ➜
2.3
1÷15 40
15÷50 40
100÷200 30
200÷420 30
Fig. 8
Fig. 7/B
NO
NO
• The installation of a filter on the suction side is always recommended, particularly when the liquid to be metered contains suspended particles.
• The characteristics of the filter net depend on the kind of liquid and pump flow rate.
For liquids with viscosity not exceeding 200 cp see table D.
• To prevent sucking of impurities, specially when liquids with solid content are
metered, the suction pipe shall not draw the liquid from the bottom of the tank.
The suction point should be 10 cm from the tank bottom (fig.8).
Examples of installation of the filter
Flow rate L/h Mesch
Table D
CAUTION! A small-sized filter will affect the metering performances.
Use Y- filters with a size larger than the suction connection.
RIGHTWRONG
Wrong
Wrong
Right
Right
SUCTION SIDE FILTER
INSTALLATION
Right
Right
Right
Suggested installation
Suggested installation
Acceptable installation
Wrong
Irregular suction
Wrong
Wrong
Wrong
RIGHTWRONG
