6 Device Description
16 / 85 Instruction Manual Pentacam® AXL (G/70100/EN 1121 Rev04)
6 Device Description
6.1 Overview of the device components
1 Ventilation opening 5 Y-cable connector
2 Measuring window 6 Cross slide
3 Camera opening 7 Sliding plate with circular markings
4 On/off switch with indicator light 8 Joystick
Fig. 6-1: Device components
1
4
7
8
6
3
2
5
