9 Pentacam® AXL Program
Instruction Manual Pentacam® AXL (G/70100/EN 1121 Rev04) 25 / 85
9 Pentacam® AXL Program
If no error message appears after starting the software with the device
connected and switched on (for example component failure, camera not
detected, missing references data, etc.), the device is safely ready for
operation.
Note
The Pentacam® AXL program is not to be used to dictate therapy without
professional correlation with other clinical findings and diagnostic tests.
Loading previous examinations
 Select the menu item [Examination] and click [Load].
The dialog box "Load Examination" appears.
 Make a selection by clicking the required examination.
 Confirm your selection by clicking [OK], or by double clicking.
The Pentacam® AXL program will load the examination you have
selected.
Starting a measurement
 Select the [Examination] tab and click [Scan].
The blue slit light is activated and the Scan menu (sec. 10, page 27)
appears.
1 Menu bar
2 Examination and Patient data
Fig. 9-1: Pentacam® AXL program menu (upper section)
1
2
