13 Test measurement with the Pentacam® AXL
Instruction Manual Pentacam® AXL (G/70100/EN 1121 Rev04) 57 / 85
12.4.3 Automatic Backup
In addition to the manually performed backup, it is also possible to
automatically run a backup when exiting the Patient Data Management
system. The settings required for this can be made in the "Settings" area,
see User Guide.
13 Test measurement with the Pentacam® AXL
13.1 Test measurement: Tomography (3D scan)
The Pentacam® AXL is tested and calibrated at OCULUS.
OCULUS Optikgeräte GmbH recommends to carry out additional regular
test measurements with the Pentacam® AXL.
Start the test with a measurement of a human eye.
Carry out at least five successive measurements on each eye. Calculate
the arithmetic mean and log the results.
Once a month, this measurement sequence should be carried out on the
same eye as described above.
Compare the arithmetic mean from the initial measurement with the cur-
rent measurement.
The following table depicts the tolerance range between the result of the
initial measurement and the result of the current measurement:
If the difference between the initial value and the current value lies out-
side the tolerance range, please contact our service or your marketing
authorisation holder. The values are shown in the overview display, for
example; please refer to the user manual.
13.2 Test measurement: Axial length
13.2.1 Attach the test eye
Tool and material
 Test eye (70108)
 1.5 mm Allen key
Procedure
 Turn off the Pentacam® AXL.
Tolerance range
Curvature
+/- 0,1 dpt
Pachymetry
+/- 10 µm
