OCULUS Pentacam AXL User Manual

8 Patient Data Management
24 / 85 Instruction Manual Pentacam® AXL (G/70100/EN 1121 Rev04)
Extended Patient Search: [Extended] Checkbox
 Click on the [Extended] checkbox.
The screen displays additional search parameters which reference
previous examinations. Proceed as for the input of a patient name.
8.2 Starting the Pentacam® AXL Software
Switching from Patient Data Management to the Pentacam® AXL
program:
 After selecting a patient: Press the [Pentacam] button to start the
Pentacam® AXL program (fig. 8-1, page 22)
or
 Double-click the selected patient name or an examination to start
the Pentacam® AXL program.
☞
Proceed a test measurement if a message appears, sec. 13, page 57.
If you do not proceed a test measurement, it will be stored in the
Pentacam® AXL program.
Fig. 8-4: Extended search
