Oki MB451 User Manual

Setup to use the WSD Scan
-106-
 Setup to use the WSD Scan
The following explains how to set up the PC to use the WSD Scan function. In order to use the WDS
Scan function, install this device on the PC.
WSD Scan can be used from Scan To Local PC and Scan To Remote PC via Network.
To use WSD Scan, the machine has to be connected with the computer which Windows Vista/
Windows7/ Windows Server 2008/ Windows Server 2008R2 was installed via Network.
Reference
 Before starting the following procedure, be sure to check the network connection. For details, see "Network
Connection" P. 47.
Note
 If a scanner is used via WSD Scan connection and if the device IP address is changed, select [Uninstall] in step 2 of
Installation procedure and uninstall the scanner, and then execute the install procedure again.
Installation procedure
Memo
 When you follow the procedure below, the WIA is installed
automatically as the scanner driver.
Note
 Before starting the installation, select [Network and
Sharing Center] from the Control Panel and make sure
that Network Search is enabled.
1 From the [Start] menu, select
[Network]. The devices connected to
the network are displayed.
2 Right-click the MB491 icon under
[Multifunction Devices] and select
[Install].
If the [User Account Control] dialog box is
displayed, click [Yes].
3 When the balloon message saying that
the installation is complete is displayed
on the task bar, click the balloon to check
the details, and click [Close].
Check the device installation on the machine as
follows.
4 Press the <SCAN> key on the operator
panel.
5 Press the to select [Local PC] and
then press .
6 Check that [Select A Connecting PC] is
selected, and press .
7 Press the to select [From WSD
Scan], and press .
8 Make sure that the device installation PC
is displayed as the destination PC.
Memo
 A maximum of 50 PCs can be registered.
OK
OK
OK

Oki MB451 Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Dimensions (WxDxH)	455 x 425 x 427 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Maximum duty cycle	30000 pages per month
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	11 s
Scan to	CIFS, Fax, FTP, USB
Grayscale levels	7
Scan speed (black)	37.5 ppm
Scan speed (color)	10 ppm
Image formats supported	BMP, GIF, JPG, PCX, PNG, TGA
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, C6, DL
Maximum print size	210 x 297 mm
Duplex media weight	60 - 112 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 150 g/m²
Display	LCD
Display resolution	320 x 128 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Security algorithms	SSL/TLS
Processor frequency	330 MHz
Sound power level (standby)	55 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	3 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	580 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
