Oki MB451 User Manual

Scanning Methods
-110-
Scan to Local PC
You can save the scanned data into your local computer.
When you press the or , the scan
job starts and the ActKey utility and the TWAIN
driver start automatically. You can send the
scanned document to a specified application,
save it in a specified folder, or send it by fax.
In the WSD Scan connection, you can set an
application to start and a location where you
send or store documents for each recipient.
The machine can be connected to USB interface
or network, but only a computer can be
connected at the same time.
If the Mac OS X is running, the image capture
and the ICA driver start up automatically.
You can select a folder and save the scanned
documents in it.
Note
 Connect the machine to a computer via USB or a network.
 Install ActKey and scanner driver before scanning to a
local computer.
 If you connect the machine to network, follow these
instructions.
-Set [TCP/IP] setting to [Enable].
- Conform the IP version of the machine to that of your
computer.
- Set up the DNS server.
- Enable the network TWAIN setting.
 If the Mac OS X is running, you can scan a document in
the fixed A4 size only on the document glass.
 If the Mac OS X 10.7 is running and if you scan documents
through network connection, you need to start the image
capture first. Then, you need to select the machine from
the list displayed at the left of image capture screen.
 To use the MFP in WSD Scan connection, set the followings.
-Set the [TCP/IP] setting of the MFP to [Enable].
- Match the IP version between the MFP and the PC.
- Enable the WSD Scan.
- Install the MFP on the PC.
Reference
 For details on how to enable the network TWAIN setting,
refer to the User's Manual Advanced.
 For details on how to install the ActKey utility, refer to the
User's Manual Advanced.
 For the procedure to enable WSD Scan, see the "User's
Manual, Applications."
 For the procedure to install the MFP on the PC, see "Setup
to use the WSD Scan" P. 106.
 Connecting via USB
1 Press the <SCAN> key on the operator panel.
2 Place your document with text face up in the
ADF or face down on the document glass.
3 Press the to select [Local PC] and
then press .
If the Network TWAIN setting is set to [Disable],
proceed to step 6.
4 Check that [Select A Connecting PC] is
selected and then press .
5 Press the to select [From USB
Interface] and then press .
6 Press the to select [Select An
Application] and then press .
7 Press the to select where to send the
scanned document and then press .
Note
 If the Mac OS X is running, you can select Folder only.
8 Press or .
Memo
 If you select [Application], the specified application starts
and the scanned image is displayed on the application.
 If you select [Folder], the scanned image is saved in the
specified folder.
 If you select [PC-FAX], the application for fax
transmission starts. After sending the scanned image,
send a fax with the fax transmission software on your
computer.
 Connecting via Network
1 Press the <SCAN> key on the operator panel.
2 Place your document with text face up in the
ADF or face down on the document glass.
3 Press the to select [Local PC] and
then press .
4 Check that select [Select A Connecting
PC] is selected and then press .
5 Check that [From Network] is selected
and then press .
6 Press the to select the computer you
want and then press .
MONO
COLOR
Selectable location Values to send:
Application Folder PC-FAX
OK
OK
OK
OK
OK
MONO
COLOR
OK
OK
OK
OK

Oki MB451 Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Dimensions (WxDxH)	455 x 425 x 427 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Maximum duty cycle	30000 pages per month
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	11 s
Scan to	CIFS, Fax, FTP, USB
Grayscale levels	7
Scan speed (black)	37.5 ppm
Scan speed (color)	10 ppm
Image formats supported	BMP, GIF, JPG, PCX, PNG, TGA
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, C6, DL
Maximum print size	210 x 297 mm
Duplex media weight	60 - 112 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 150 g/m²
Display	LCD
Display resolution	320 x 128 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Security algorithms	SSL/TLS
Processor frequency	330 MHz
Sound power level (standby)	55 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	3 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	580 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
