Oki MB451 User Manual

Connecting to a Computer
-51-
Setup
1
3 Press the to select [Network Setup],
and then press the .
4 Press the to select [Wireless
Setting], and then press the .
5 Press the to select [Wireless
reconnection], and then press .
6 Press the to select [Yes], and then
press .
7 When [Yes] is selected in step 6,
[Searching for connection...] is
displayed in the screen.
After this, [Connection successful] is
displayed, and the wireless LAN can be
used on this equipment.
Memo
 If [A Timeout occurred.] is displayed, the connection
destination wireless AP may not have been found within
the required time. The SSID, security settings, and KEY
need to be configured to match the wireless AP settings.
Check each of the settings. For details on each of the
setting items, see "Using the wireless LAN".
 Switching from wireless to wired
The network connection method can be switched
from wireless to wired.
1 Log in as the administrator.
2 Press the to select [Network Menu],
and then press the .
3 Press the to select [Network Setup],
and then press the .
4 Press the to select [Enabling Wired
Communications], and then press .
5 Press the to select [Yes], and then
press .
Install a Printer and Fax Driver
(for Windows)
To complete the network connection with a
Windows computer, first set IP addresses for the
machine, and then install a printer and fax driver
on the computer.
If there is no DHCP server or BOOTP server on
the network, you need to manually configure the
IP address on the computer or machine.
Your network administrator or Internet service
provider specifies a unique IP address for the
computer and your machine. Set the IP
addresses manually.
Note
 You need to complete the network setting of the computer
before this procedure.
 To complete this procedure, you must be logged in as an
administrator.
 When setting an IP address manually, ask the network
administrator or your Internet service provider which IP
address to use. If the IP address is set wrong, the network
may go down or Internet access may be disabled.
OK
OK
OK
OK

Oki MB451 Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Dimensions (WxDxH)	455 x 425 x 427 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Maximum duty cycle	30000 pages per month
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	11 s
Scan to	CIFS, Fax, FTP, USB
Grayscale levels	7
Scan speed (black)	37.5 ppm
Scan speed (color)	10 ppm
Image formats supported	BMP, GIF, JPG, PCX, PNG, TGA
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, C6, DL
Maximum print size	210 x 297 mm
Duplex media weight	60 - 112 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 150 g/m²
Display	LCD
Display resolution	320 x 128 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Security algorithms	SSL/TLS
Processor frequency	330 MHz
Sound power level (standby)	55 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	3 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	580 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
