Oki MB451 User Manual

Basic Settings for Faxing (for MB451, MB451w, MB471, MB471w, MB491, ES4191 MFP only)
-45-
Setup
1
12 When the setup menu screen is displayed,
press to complete the setup.
PBX Connecting
When connecting to PBX (internal exchange), put
[PBX Line] to [ON].
1 Press the <SETTING> key.
2 Press the to select [Admin Setup]
and then press .
3 Enter the administrator password.
The default password is "aaaaaa".
4 Select [Enter] and then press .
5 Press the to select [Fax Setup] and
then press .
6 Press the to select [Fax Setting] and
then press .
7 Press the to select [PBX Line] and
then press .
8 Press the to select [ON] and then
press .
9 Press the until the top screen appears.
Setting for Super G3
1 Press the <SETTING> key.
2 Press the to select [Admin Setup]
and then press .
3 Enter the administrator password.
The default password is "aaaaaa".
4 Select [Enter] and then press .
5 Press the to select [User Install] and
then press .
6 Press the to select [Super G3] and
then press .
7 Press the to select [OFF] and then
press .
8 Press the until the top screen appears.
Specifying Reception Mode
The optimal reception mode differs depending on
the environment for your machine. Refer to the
following description.
 Fax Ready Mode
This mode is recommended when you use the
machine as a fax machine.
 Tel/Fax Ready Mode
This mode is recommended when you connect an
external phone to the machine.
 Ans/Fax Ready Mode
This mode is recommended when you connect an
external answering machine to the machine.
 Tel Ready Mode
This mode is recommended when you generally
use an external phone connected to the machine.
 DRD
This mode is recommended when you use the
distinctive ring detection (DRD) function provided
by a telephone company.
1 Press the <SETTING> key on the
operator panel.
2 Press the to select [Admin Setup]
and press .
3 Enter the administrator password.
The factory default password is "aaaaaa".
4 Select [Enter] and press .
5 Press the to select [User Install] and
press .
6 Press the to select [Reception Mode]
and press .
7 Press the to specify the reception
mode and press .
8 Press the until the fax start screen
appears.
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
Settable Reception Mode:
Fax Ready Mode* Tel/Fax Ready Mode
Ans/Fax Ready Mode Tel Ready Mode DRD
*indicates the factory default.
OK
OK
OK
OK
OK

Oki MB451 Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Dimensions (WxDxH)	455 x 425 x 427 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Maximum duty cycle	30000 pages per month
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	11 s
Scan to	CIFS, Fax, FTP, USB
Grayscale levels	7
Scan speed (black)	37.5 ppm
Scan speed (color)	10 ppm
Image formats supported	BMP, GIF, JPG, PCX, PNG, TGA
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, C6, DL
Maximum print size	210 x 297 mm
Duplex media weight	60 - 112 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 150 g/m²
Display	LCD
Display resolution	320 x 128 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Security algorithms	SSL/TLS
Processor frequency	330 MHz
Sound power level (standby)	55 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	3 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	580 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
