Oki MB451 User Manual

Configuring Fax Settings
-88-
 Configuring Fax Settings
You can configure the fax settings to alter the output to suit your needs. Each setting can be configured
from the [Fax Functions] menu on the fax start screen.
Perform the following procedures at step 6 of "Sending a Fax" P. 85 described above.
Changing Scan Size (Scan Size)
You can select the appropriate scan size for your
document.
1 Press the to select [Fax Functions]
on the fax start screen and then press
.
2 Check that [Scan Size] is selected and
then press .
3 Press the to select a size and then
press .
4 Press the until the fax standby screen
appears.
Changing Resolution
(Resolution)
You can select an appropriate resolution to scan
your fax document to get optimum image quality.
1 Press the to select [Fax Functions]
on the fax standby screen and then
press .
2 Press the to select [Resolution] and
then press .
3 Press the to select a resolution and
then press .
Memo
 [Extra-Fine] may be unavailable depending on the
recipient machine.
 In the [Fine], [Extra-Fine], or [Photo] mode,
scanning takes longer.
4 Press the until the fax standby screen
appears.
Adjusting Density (Density)
You can adjust the scan density from 7 levels.
1 Press to select [ Fax Functions ] on the
fax standby screen and then press .
2 Press the to select [Density] and
then press .
3 Press the or to select a density and
then press .
Memo
 [0] is the standard value. To darken the document
image, select [+1], [+2] or [+3] (most dense).
Conversely, to lighten the document image, select
[- 1], [-2] or [-3] (least dense).
4 Press the until the fax standby screen
appears.
Printing the Sender Name
You can set the machine to print a sender name
on faxes you send. By default, the name you
specified in [Sender ID] is printed.
Reference
 For details on [Sender ID], refer to "Specifying Sender
Information" P. 44.
1 Press the to select [Fax Functions]
on the fax standby screen and then
press .
2 Press the to select [TTI] and then
press .
3 Press the to select [ON] and then
press .
4 Press the until the fax start screen
appears.
Reference
 For details on how to register a sender name and change
the sender name to be used, refer to the Use's Manual
Advanced.
Settable Size Values:
A4* Letter Legal 13 Legal 13.5
Legal 14
*indicates the factory default.
Settable Resolution:
Normal* Fine Extra-Fine Photo
*indicates the factory default.
OK
OK
OK
OK
OK
OK
Values:
+3 +2 +1 0* -1 -2 -3
*indicates the factory default.
OK
OK
OK
OK
OK
OK

Oki MB451 Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Dimensions (WxDxH)	455 x 425 x 427 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Maximum duty cycle	30000 pages per month
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	11 s
Scan to	CIFS, Fax, FTP, USB
Grayscale levels	7
Scan speed (black)	37.5 ppm
Scan speed (color)	10 ppm
Image formats supported	BMP, GIF, JPG, PCX, PNG, TGA
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, C6, DL
Maximum print size	210 x 297 mm
Duplex media weight	60 - 112 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 150 g/m²
Display	LCD
Display resolution	320 x 128 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Security algorithms	SSL/TLS
Processor frequency	330 MHz
Sound power level (standby)	55 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	3 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	580 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
