Omron 3G3AX-MX2-ECT User Manual

A-3
Appendices
EtherCAT Communication Unit USER’S MANUAL (3G3AX-MX2-ECT)
A-1 Specifications
App
A-1-3 EtherCAT Communications Specifications
A-1-3 EtherCAT Communications Specifications
Item Specifications
Communications standard IEC 61158 Type12, IEC 61800-7 CiA 402 drive profile
Physical layer 100BASE-TX (IEEE802.3)
Connector RJ45  2 (shielded type)
ECAT IN: EtherCAT input
ECAT OUT: EtherCAT output
Communications media Category 5 or higher (cable with double, aluminum tape and braided shielding) is
recommended.
Communications distance Distance between nodes: 100 m max.
Process data Fixed PDO mapping
PDO mapping
Mailbox (CoE) Emergency messages, SDO requests, SDO responses, and SDO information
Distributed clock FreeRun mode (asynchronous)
LED display L/A IN (Link/Activity IN)  1
L/A OUT (Link/Activity OUT)  1
RUN  1
ERR  1
CiA402 drive profile Velocity mode

Omron 3G3AX-MX2-ECT Specifications

General

Brand	Omron
Model	3G3AX-MX2-ECT
Category	Controller
Language	English
