Omron 3G3RX-V1 Series User Manual

7．Connection Procedure
12
7.2. Work Flow
Take the following steps to make connection settings for remote I/O communications of
DeviceNet.
7.3. Setting Up the Inverter
Set up the Inverter.
↓
7.3.1 Hardware Setting Mount the DeviceNet Communications Unit on the
Inverter.
↓
7.3.2 Parameter Setting Set the parameters for the Inverter.
↓
7.4. Setting up the Controller
Set up the Controller.
↓
7.4.1 Hardware Setting for DeviceNet
Unit
Set the hardware switches on the DeviceNet Unit
and connect to the Controller.
↓
7.4.2. Starting the Sysmac Studio and
Importing the Project File
Start the Sysmac Studio and import the Sysmac
Studio project file.
↓
7.4.3 Connecting Online and
Transferring the Project Data
Connect online with the Sysmac Studio and transfer
the project data to the Controller.
↓
7.5 Setting Up the Network
Set up remote I/O communications of DeviceNet.
↓
7.5.1. Starting the CX-Integrator and
Opening the Project File
Start the CX-Integrator and open the CX-Integrator
project file.
↓
7.5.2. Connecting Online and
Transferring a Scan List
Connect online with the Controller, and transfer the
setting (scan list) of the set device to the DeviceNet
Unit via the Controller.
↓
7.6. Connection Status Check
Check the connection status of the DeviceNet
network.
↓
7.6.1. Checking the Connection Status Confirm that the DeviceNet communications is
normally performed.
↓
7.6.2. Checking Data that are Sent
and Received
Confirm that the correct data are sent and received.
