A - 27
A Appendices
E5@C Digital Temperature Controllers User’s Manual (H174)
A-6 Parameter Operation Lists
A
A-6-2 Adjustment Level
*1 This setting is not displayed for heating and cooling control or for floating position-proportional control.
*2 Seconds is supported only by the E5DC, E5DC-B, and E5GC. (The E5DC must be manufactured in July 2014 or later
(version 2.2 or higher).)
Integral Time (Cooling) c-i Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
233
233.0
Seconds
Derivative Time
(Cooling)
c-d Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
40
40.0
Seconds
Dead Band c-db Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −19.99 to 99.99 0.00 %FS
Manual Reset Value of-r 0.0 to 100.0 50.0 %
Hysteresis (Heating) hys Temperature input: 0.1 to 999.9 1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
Hysteresis (Cooling) chys Temperature input: 0.1 to 999.9 1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
Soak Time
soak 1 to 9999 1
min, h, or s
*2
Wait Band
wt-b Temperature input: OFF or 0.1 to 999.9
off, 0.1 to
999.9
OFF °C or °F
Analog input: OFF, 0.01 to 99.99
off, 0.01 to
99.99
OFF %FS
MV at Stop
mv-s Standard: −5.0 to 105.0
Heating/cooling: −105.0 to 105.0
0.0 %
Floating position-proportional control or the Direct
Setting of Position-proportional MV parameter set
to OFF: CLOS, HOLD, or OPEN
clos, hold,
open
HOLD None
Close position-proportional control with the Direct
Setting of Position-proportional MV parameter set
to ON: −5.0 to 105.0
0.0 %
MV at PV Error
mv-e Same as the MV at Stop parameter. 0.0 %
SP Ramp Set Value sprt OFF, 1 to 9,999
off, 1 to
9999
OFF EU/s,
EU/min,
EU/h
SP Ramp Fall Value sprl SAME, OFF, or 1 to 9,999
same, off,
1 to 9999
SAME EU/s,
EU/min,
EU/h
MV Upper Limit ol-h Standard control: MV lower limit + 0.1 to 105.0
Heating/cooling control: 0.0 to 105.0
100.0 %
Close position-proportional control: MV lower limit
+ 0.1 to 105.0
MV Lower Limit ol-l Standard control: −5.0 to MV upper limit − 0.1 0.0 %
Heating/cooling control: −105.0 to 0.0 −100.0
Close position-proportional control: −5.0 to MV
upper limit −0.1
0.0
MV Change Rate Limit orl 0.0 to 100.0
(0.0: MV Change Rate Limit Disabled)
0.0 %/s
Position Proportional
Dead Band
db Close position-proportional control: 0.1 to 10.0 4.0 %
Floating position-proportional control: 0.1 to 10.0 2.0
Open/Close Hysteresis oc-h 0.1 to 20.0 0.8 %
Extraction of Square
Root Low-cut Point
sqrp 0.0 to 100.0 0.0 %
Work Bit * ON Delay
w1
to 8on
0 to 999 0 Seconds
Work Bit * OFF Delay
w1
to 8of
0 to 999 0 Seconds
Communications
Monitor
plcm 0 to 9999 ms
Parameters Characters Setting (monitor) value Display Default Unit
000
000
000
000
000
000
000
000
000
