2 - 5
2 CompoWay/F Comm
unications Procedures
E5@C Digital Temperature Controllers Communica
tions Manual (H175)
2-1 Data Format
2
2-1-5 End Code Example
Example 4) No Sub-address and Illeg
al BCC
•
Command
•
Response
The sub-address i
s “00”
and the end code is
“13” (BCC error).
STX
ETX
Node number
BCC
Err
0E
T
X
End code
BCC
13
STX
0
Node number
Sub-address
36
38
