3 Communications Data for CompoWay/F
3 - 2
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
• For communications using a variable type not enclosed in parentheses in the following table, the set
value is double-word data (8 digits). For communications using a variable type enclosed in
parentheses, the set value is single-word data (4 digits).
• For example, variable type C0 is double-word data (8 digits), and variable type 80 is single-word data
(4 digits).
• Items expressed in hexadecimal in the "Setting (monitor) value" column are the setting range for
CompoWay/F communications. The values in parentheses are the actual setting range. When there
is a section reference for a setting item, refer to that reference for details.
*1 Not displayed on the Controller display.
*2 When the variable type is 80 (word access), the rightmost 16 bits are read.
*3 When the variable type is 80 (word access), the leftmost 16 bits are read.
*4 You can use this selection only with the E5EC-PR@-8@@ or E5AC-PR@-8@@. (The Digital Controller must
be manufactured in August 2014 or later (version 2.2 or higher).)
Variable
type
Address Parameter name Setting (monitor) value Level
C0 (80) 0000 PV Temperature: Use the specified range for each sensor.
Analog: Scaling lower limit −5% FS to Scaling
upper limit +5% FS
Operation
C0 (80) 0001
Status
*1*2
Refer to 3-2 Status and Status 2 for details.
C0 (80) 0002
Internal Set Point
*1
SP lower limit to SP upper limit
C0 (80) 0003 Heater Current 1
Value Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0004 MV Monitor
(Heating)
Standard: H'FFFFFFCE to H'0000041A
(−5.0 to 105.0)
Heating and cooling: H'00000000 to H'0000041A
(0.0 to 105.0)
C0 (80) 0005 MV Monitor
(Cooling)
H'00000000 to H'0000041A (0.0 to 105.0)
C0 (80) 0006 Heater Current 2
Value Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0007 Leakage Current 1
Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0008 Leakage Current 2
Monitor
H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0009 Soak Time Remain H'00000000 to H'0000270F (0 to 9999)
C0 (80) 000A Valve Opening
Monitor
H'FFFFFF9C to H'0000044C (−10.0 to 110.0):
Measured opening
H'00000000 to H'000003E8 (0.0 to 100.0): Estimated
opening
*4
C0 (80) 000B Remote SP Monitor Remote SP lower limit −10%FS to Remote SP upper
limit +10%FS
C0 (80) 000C Multi-SP No.
Monitor
H'00000000 to H'00000007 (0 to 7)
C0 (80) 000E Decimal Point
Monitor
*1
H'00000000 to H'00000003 (0 to 3)
C0 (80) 0011
Status 2
*1*2
Refer to 3-2 Status and Status 2.
C0 (80) 0012
Status
*1*3
Refer to 3-2 Status and Status 2.
C0 (80) 0013
Status 2
*1*3
Refer to 3-2 Status and Status 2.
