Omron E5EC Communications Manual

3 Communications Data for CompoWay/F
3 - 26
E5@C Digital Temperature Controllers Communications Manual (H175)
 Status 2 Details
Note1 “Spare” bits are always OFF.
2 When read in setup area 1, the status of the bits will be as follows:
Bit position Status
Bit Description
0 1
Status
(lower
word)
0 Work bit 1 OFF ON
1 Work bit 2 OFF ON
2 Work bit 3 OFF ON
3 Work bit 4 OFF ON
4 Work bit 5 OFF ON
5 Work bit 6 OFF ON
6 Work bit 7 OFF ON
7 Work bit 8 OFF ON
8 Spare OFF ---
9 Spare OFF ---
10 Spare OFF ---
11 Spare OFF ---
12 Spare OFF ---
13 Spare OFF ---
14 Spare OFF ---
15 Spare OFF ---
Status
(upper
word)
16 Event input 5 OFF ON
17 Event input 6 OFF ON
18 Spare OFF ---
19 Spare OFF ---
20 Invert direct/reverse operation Not invert Invert
21 SP ramp OFF During SP ramp
22 Spare OFF ---
23 Spare OFF ---
24 Spare OFF ---
25 Spare OFF ---
26 Spare OFF ---
27 SP Mode Local SP Mode Remote SP Mode
28 Alarm 4 OFF ON
29 Spare OFF ---
30 Spare OFF ---
31 Spare OFF ---
• Work bits 1 to 8: Cleared
• SP ramp: Last value held
