4 Installation and Wiring
4-34
NJ-series CPU Unit Hardware User’s Manual (W500)
For details on using OMRON Connecting Cables equipped with special connectors to connect Basic
I/O Units with connectors to OMRON Connector-Terminal Block Conversion Units or I/O Relay Termi-
nals, refer to A-2-4 Connecting Connector-Terminal Block Conversion Units and I/O Relay Terminals.
 Available Connectors
Use the following connectors when assembling a connector and cable.
CJ-series 32- and 64-point Basic I/O Units with Fujitsu Connectors
Connecting to a Connector-Terminal Block Conversion Unit or I/O
Relay Terminal
Using User-made Cables with Connector
Applicable Units
Model Specifications Pins
CJ1W-ID231 Input Unit, 24 VDC, 32 inputs 40
CJ1W-ID261 Input Unit, 24 VDC, 64 inputs
CJ1W-OD231 Transistor Output Unit with Sinking Outputs, 32 outputs
CJ1W-OD261 Transistor Output Unit with Sinking Outputs, 64 outputs
CJ1W-MD261 24-VDC Input/Transistor Output Units, 32 Inputs, 32 Outputs
CJ1W-MD231 24-VDC Input/Transistor Output Units, 16 Inputs, 16 Outputs 24
Applicable Cable-side Connectors
Connection Pins OMRON set Fujitsu parts
Solder-type 40 C500-CE404 Socket: FCN-361J040-AU
Connector cover: FCN-360C040-J2
24 C500-CE241 Socket: FCN-361J024-AU
Connector cover: FCN-360C024-J2
Crimped 40 C500-CE405 Socket: FCN-363J040
Connector cover: FCN-360C040-J2
Contacts: FCN-363J-AU
24 C500-CE242 Socket: FCN-363J024
Connector cover: FCN-360C024-J2
Contacts: FCN-363J-AU
Pressure-welded 40 C500-CE403 FCN-367J040-AU/F
24 C500-CE243 FCN-367J024-AU/F
