3 Configuration Units
3-14
NJ-series CPU Unit Hardware User’s Manual (W500)
3-3 Power Supply Units
Use an NJ-series Power Supply Unit to supply power to an NJ-series CPU Rack or Expansion Rack.
Precautions for Correct UsePrecautions for Correct Use
• Do not use the Power Supply Units in the system beyond the rated supply capacity range
given in the following specifications. Doing so may result in operation stopping, incorrect oper-
ation, or failure to correctly back up required data at power interruptions.
• Use only NJ-series Power Supply Units on NJ-series CPU Racks and Expansion Racks. Oper-
ation is not possible if you use a CJ-series Power Supply Unit with an NJ-series CPU Unit or
an NJ-series Power Supply Unit with a CJ-series CPU Unit.
3-3-1 Models and Specifications
NJ-series Power Supply Units
Item Specifications
Model NJ-PA3001 NJ-PD3001
Supply voltage 100 to 240 VAC (wide-range), 50/60 Hz 24 VDC
Operating voltage
and frequency
ranges
85 to 264 VAC, 47 to 63 Hz 19.2 to 28.8 VDC
Power consumption 120 VA max. 60 W max.
Inrush current
*1
At 100 VAC:
20 A/8 ms max. for cold start at room tempera-
ture
At 200 VAC:
40 A/8 ms max. for cold start at room tempera-
ture
At 24 VDC:
30 A/20 ms max. for cold start at room tempera-
ture
Output capacity
*2
5 VDC, 6.0 A (including supply to CPU Unit using CPU Rack)
5 VDC, 6.0 A (using Expansion Rack)
24 VDC, 1.0 A
To ta l : 30 W m a x .
Output terminal (ser-
vice supply)
Not provided
RUN output
*3
Contact configuration: SPST-NO
Switch capacity: 250 VAC, 2 A (resistive load)
120 VAC, 0.5 A (inductive load), 24 VDC, 2A (resistive load)
Replacement notifi-
cation function
Not provided.
Insulation resis-
tance
*4
20 M min.
(at 500 VDC) between AC external and GR ter-
minals
20 M min.
(at 500 VDC) between DC external and GR ter-
minals
Dielectric
strength
*4*5
2,300 VAC 50/60 Hz for 1 min between AC
external and GR terminals
Leakage current: 10 mA max.
1,000 VAC 50/60 Hz for 1 min between DC
external and GR terminals
Leakage current: 10 mA max.
Noise immunity 2 kV on power supply line (Conforms to IEC 61000-4-4.)
Vibration resistance
5 to 8.4 Hz, 3.5-mm amplitude, 8.4 to 150 Hz, acceleration: 9.8 m/s
2
in X, Y, and Z directions for
100 minutes (Time coefficient: 10 minutes coefficient factor 10 = total time 100 min.) (according to
IEC 60068-2-6)
To Next Page
