3-13
3 Configuration Units
NJ-series CPU Unit Hardware User’s Manual (W500)
3-2 SD Memory Cards
3
3-2-3 Installing and Removing
3 Push the SD Memory Card securely into the compartment.
1 Press the SD Memory Card power supply switch (SD PWR).
2 Press the SD Memory Card after the SD BUSY indicator is no longer lit.
The SD Memory Card will be ejected from the compartment.
3 Pull out the SD Memory Card.
4 Close the Memory Card cover when an SD Memory Card is not being used.
Removing the SD Memory Card
SD Memory Card
power supply switch
To Next Page
