1 Introduction to NJ-series Controllers

NJ-series CPU Unit Hardware User’s Manual (W500)

1-3 Overall Operating Procedure

for the NJ-series Controller

1-3-1 Overall Procedure

1-3 Overall Operating Procedure for the

NJ-series Controller

This section gives the overall operating procedure of the NJ-series Controllers and then describes it in

more detail.

The overall procedure to use an NJ-series Controller is given below.

1-3-1 Overall Procedure

Step 1. Software Design

Design the overall system configuration, task configuration, programs, and vari-

ables.

Step 1-1 Designing I/O and Processing

Step 1-2 Designing Tasks

Step 1-3 Designing Programs

Step 2. Software Setups and Programming

Create the system configurations that you designed in step 1 on the Support Soft-

ware and assign the variables. Create the tasks and programs, and debug them,

e.g., with simulations.

Step 2-1 Slave and Unit Configurations

Step 2-2 Controller Setup

Step 2-3 Programming

Step 2-4 Offline Debugging

Step 3. Mounting and Setting Hardware

Mount the Units and make the required hardware settings.

Step 4. Wiring

Connect the network cables and wire the I/O.

Step 5. Confirming Operation and Starting Actual System

Operation

Connect the Support Software to the physical system and download the project.

Check operation on the physical system and then start actual system operation.
