2-24
2-3
External and Mounted Dimensions
Dimensions are shown in millimeters.
2-3-1
AC Servo Drivers
H
Single-phase
100
V
: R88D-WT
A3HL/-WT
A5HL/-WT01HL (30 to 100 W)
Single-phase 200 V
: R88D-WT
A3H/-WT
A5H/-WT01H/-WT02H (30 to 200 W)
D
W
all Mounting
External dimensions
Mounted dimensions
T
wo, M4
D
Front Panel Mounting (Using Mounting Brackets)
External dimensions
Mounted dimensions
5 dia.
T
wo, M4
Standard Models and Specifications
Chapter 2
