Omron R88M-W User Manual

1-7
1-2 System Configuration
Position Control Unit
CJ1W-NC113/213/413
CJ1W-NC133/233/433
CS1W-NC113/213/413
CS1W-NC133/233/433
C200HW-NC113/213/413
C500-NC113/211
Motion
Control
Unit
CS1W-MC221/421(-V1)
CV500-MC221/421
C200H-MC221
C500-NC222-E
Position Control
Unit
Controller with Voltage Output
Controller with Pulse Train Output
R88A-PR02W Parameter
Unit
(Hand-held)
OMNUC W-series
AC Servo Driver
R88D-WTj
OMNUC W-series AC
Servomotor
R88M-Wj
SYSMAC CS-, C-, or
CV-series
Programmable
Controller
[Incremental] [Absolute]
Analog voltage
Pulse train
SYSMAC CJ, CS-, C-, or
CV-series
Programmable
Controller
Single-axis Positioner with Pulse String Output
DeviceNet Single-axis Positioner
3F88M-DRT141
DeviceNet Option
Unit
R88A-NCW152-DRT
Controller (MECHATROLINK-II Compatible)
Programmable Controller
SYSMAC CS Series
Motion Control Unit
CS1W-MCH71
MECHATROLINK-II
Option Unit
JUSP-NS115
(OMRON model
number: FNY-NS115)
MECHATROLINK-II
Note 1. Servomotors with absolute encoders can be used in combination with CS1W-
MC221/421(-V1), CV500-MC221/421, C200H-MC221, or CS1W-MCH71 Motion Control
Units, with the 3F88M-DRT141 DeviceNet Single-axis Positioner, or with the
R88A-NCW152-DRT DeviceNet Option Unit.
