3-82
3-8 Reactor Specifications
3
Specifications
3-8 Reactor Specifications
A Reactor is connected to the Servo Drive as a harmonic current control measure. Select a model
matching the Servo Drive to be used.
 Specifications
Reactor type
Specifications
Model Rated current (A) Inductance (mH) Weight (kg)
Single-phase
Reactors
3G3AX-DL2002 1.6 A 21.4 mH 0.8 kg
3G3AX-DL2004 3.2 A 10.7 mH 1.0 kg
3G3AX-DL2007 6.1 A 6.75 mH 1.3 kg
Three-phase
Reactor
3G3AX-AL2025 10 A 2.8 mH 2.8 kg
