2-2 External and Mounted Dimensions
2
Standard Models and Dimensions
Parameter Unit Dimensions
R88A-PR02G
Mini DIN 8-pin
MD connector
(62)
(24)
(15)
(1500)
M3, depth: 5
(114)
(15)
