Omron SYSMAC CJ1W-SCU31-V1 User Manual

485
Appendix G
E5@K Digital Controller Write Protocol
The E5@K Digital Controller Write Protocol writes and controls various settings in remote mode for the Control-
ler connected to the Serial Communications Unit/Board via RS-232C or RS-485 cable.
Note Negative values cannot be written. All values must be set as unsigned BCD.
Structure of the Protocol
The following table shows the structure of the E5@K Digital Controller Write Protocol.
Note 1. The hexadecimal equivalents of sequences numbers are given in parentheses.
2. Ladder Interface Settings
YES: User settings are required for the 3rd or 4th operands of PMCR.
Sequence
No.
Communications
sequence name
Function Ladder interface
Send word
allocation
Receive word
allocation
050 (0032) Write set point Writes the set point. Yes No
051 (0033) Write alarm value Writes alarm value 1, 2. Yes No
052 (0034) Write proportional band,
integral time, and derivative
time
Writes the proportional band, integral
time, and derivative time.
Ye s N o
053 (0035) Write cooling coefficient Writes the cooling coefficient. Yes No
054 (0036) Write dead band Writes the dead band. Yes No
055 (0037) Write manual reset value Writes the manual reset value. Yes No
056 (0038) Write hysteresis Writes the hysteresis (heating, cooling) Yes No
057 (0039) Write control period Writes the control period (heating,
cooling)
Ye s N o
058 (003A) Write SP ramp time units
and set value
Writes the SP ramp time unit and SP
ramp set value.
Ye s N o
059 (003B) Write LBA detection time Writes the LBA detection time. Yes No
060 (003C) Write MV at stop time and
PV error
Writes the MV at stop and the MV at PLC
error.
Ye s N o
061 (003D) Write MV limits Writes the MV limits. Yes No
062 (003E) Write input digital filter Writes the input digital filter. Yes No
063 (003F) Write alarm hysteresis Writes alarm 1, 2 hysteresis. Yes No
064 (0040) Write input shift values Writes the input shift values. Yes No
065 (0041) Write level 0 parameters Writes parameters in level 0. Yes No
066 (0042) Write level 1 parameters 1 Writes parameters in level 1. Yes No
067 (0043) Write level 1 parameters 2 Writes parameters in level 1. Yes No
068 (0044) Write level 2 parameters 1 Writes parameters in level 2. Yes No
069 (0045) Write level 2 parameters 2 Writes parameters in level 2. Yes No
070 (0046) General-purpose write Writes the value of the specified
parameter.
Ye s N o
071 (0047) Switch to level 0
(software reset)
Switches the setting level to level 0. Yes No
072 (0048) Run/stop Initiates Run or Stop. Yes No
073 (0049) Remote/local Switches the mode to remote or local. Yes No
074 (004A) Execute/cancel AT Executes or cancels AT. Yes No
075 (004B) Switch to level 1 Switches the setting level to level 1. Yes No
076 (004C) Software reset Resets the E5@K. Yes No
