7-23
7 PLC Setup
CP2E CPU Unit Software User’s Manual(W614)
7-2 PLC Setup Settings
7
7-2-11 Pulse Output 3 Settings
Origin Search Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Use define origin operation Do not use. Do not use. When power is turned ON
Use.
1-1 Search Direction CW CW At start of operation
CCW
1-2 Detection Method Method 0 Method 0 At start of operation
Method 1
Method 2
1-3 Search Operation Inverse 1 Inverse 1 At start of operation
Inverse 2
1-4 Operation Mode Mode 0 Mode 0 At start of operation
Mode 1
Mode 2
1-5 Origin Input Signal NC NC When power is turned ON
NO
1-6 Proximity Input Signal NC NC At start of operation
NO
1-7 Search High Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
1-8 Search Proximity Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
1-9 Origin Compensation Value 0 pps -2,147,483,648 At start of operation
:
0
:
+2,147,483,647
1-10 Origin Search Acceleration Ratio
(Rate)
0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
1-11 Origin Search Deceleration Ratio
(Rate)
0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
1-12 Positioning Monitor Time 0 (ms) 0 (ms) At start of operation
:
9,999 (ms)
