Basic Concepts Section 2-1
SIGNED BINARY-TO-BCD: BCDS(471), and DOUBLE SIGNED BINARY-TO-
BCD: BDSL(473). Refer to the CS/CJ-series Programmable Controllers Pro-
gramming Manual (W340) for more information.
Decimal Hexadecimal Binary BCD
0 0 0000 0000
1 1 0001 0001
2 2 0010 0010
3 3 0011 0011
4 4 0100 0100
5 5 0101 0101
6 6 0110 0110
7 7 0111 0111
8 8 1000 1000
9 9 1001 1001
10 A 1010 0001 0000
11 B 1011 0001 0001
12 C 1100 0001 0010
13 D 1101 0001 0011
14 E 1110 0001 0100
15 F 1111 0001 0101
16 10 10000 0001 0110
Decimal Unsigned binary (4-digit
hexadecimal)
Signed binary (4-digit
hexadecimal)
+65,535 FFFF Cannot be expressed.
+65534 FFFE
.
.
.
.
.
.
+32,769 8001
+32,768 8000
+32,767 7FFF 7FFF
+32,766 7FFE 7FFE
.
.
.
.
.
.
+2 0002 0002
+1 0001 0001
0 0000 0000
–1 Cannot be expressed. FFFF
–2 FFFE
.
.
.
–32,767 8001
–32,768 8000
