101
RFID System
User’s Manual
SECTION 5
V600-V680 Command Correspondence
SECTION 5
Communications
V600-V680 Command Correspondence
Either V680 or V600 commands can be used for the V680-series ID Controllers. V600 commands can be
used in applications in which V600-series ID Controllers were previously used so that the application does not
have to be changed. V680 command can be used to take advantage of newly implemented functions.
The command series that is being used is specified on pin 10 of DIP switch SW3. V680 and V600 commands
corresponds as shown in the following tables.
Commands for Tag Communications
Communications Subcommands
V680 Commands V600 Commands
Name
Com-
mand
code
Commu-
nications
designa-
tion
Data
designa-
tion
Name
Com-
mand
code
Data
designa-
tion
READ
RD
ST A/H READ RD A/H
ST A/H EXPANSION READ XR A/H
SA A/H AUTO READ AR A/H
PA A/H POLLING AUTO READ PR A/H
WRITE
WT
ST A/H WRITE WT A/H
ST A/H EXPANSION WRITE XW A/H
SA A/H AUTO WRITE AW A/H
PA A/H POLLING AUTO WRITE PW A/H
DATA FILL
DF
ST A/H DATA FILL DF A/H
SA A/H AUTO DATA FILL AF A/H
DATA CHECK MD ST C/K DATA CHECK MD C/K
OVERWRITE COUNT CONTROL MD ST S/L OVERWRITE COUNT CONTROL MD S/L
WRITE REPEAT RP - - WRITE REPEAT RP -
COPY CP ST H COPY CP H
AUTO COPY AP ST H AUTO COPY AP H
LARGE READ ER ST A/H LARGE READ ER A/H
READ TAG MEMORY ERROR
CORRECTION
QR ST A/H - - -
WRITE TAG MEMORY ERROR
CORRECTION
QW ST A/H - - -
V680 Commands V600 Commands
Name
Com-
mand
code
Data
desig-
nation
Name
Com-
mand
code
Data
desig-
nation
POLLING QUERY
PC C/E
POLLING QUERY PR C/E
PW C/E
COMMAND PROCESSING TERMINATE AA - COMMAND PROCESSING TERMINATE AA -
ABORT XZ - ABORT XZ -
