256
SECTION 7
Characteristics According to Operating Conditions
RFID System
User’s Manual
SECTION 7
Appendices
Characteristics According to Operating Conditions
Communications Area (Reference)
The following diagram shows the communications area for the V680 Series. The communications area
depends on the installation conditions and environmental conditions.
The following diagram shows the communications area when a Tag passes by and perpendicular to the
center of the Antenna. The Antenna and Tag surfaces are parallel to each other.
Distance in y-axis direction (mm)
Distance in x-axis direction (mm)
0
10
20
30
40
50
60
70
−70 −60 −50 −40 −30 −20 −100 10203040506070
X
Y
• Read/Write
● V680-HS63 & V680-D2KF67
