SECTION 7
Specifications and Dimensions
RFID System
User’s Manual
SECTION 7
Appendices
Specifications and Dimensions
General Specifications
Communications Specifications
Item
Specifications
RS-232C RS-422/RS-485
Connector specifica-
tions
9-pin D-sub connector socket; M2.6 lock screws 5-pin connector manufactured by Phoenix Con-
tact: MC1.5/5GF-3.5
Communications
method
Half-duplex serial 4-/2-wire half duplex serial
Baud rate 9,600 bps, 19,200 bps, 38,400 bps, or 115,200 bps
Data length 7/8 bits
Stop bit length 1/2 bits
Error detection Parity (even/odd/none)
Cable length 15 m max. Total length: 500 m max.
Item Specifications
Supply voltage (power
consumption)
24 VDC +10%/
−15% (15 W max., 0.8 A max.)
Ambient operating
temperature
−10 to 55°C (with no icing)
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient storage tem-
perature
−25 to 65°C (with no icing)
Ambient storage
humidity
25% to 85% (with no condensation)
Insulation resistance 20 M
Ω min. (at 500 VDC) between power supply terminals and casing and between the ground and
power supply terminals
Dielectric strength 1000 VAC (50/60 Hz) for 1 minute between power supply terminals and casing and between the
ground and power supply terminals
Vibration resistance
Destruction: 10 to 150 Hz, 0.2-mm double amplitude at 15 m/s
2
in X, Y, and Z directions ten sweeps
each for 8 minutes
Shock resistance 150 m/s
2
Dimensions 105 × 90 × 65 mm (excluding protruding parts)
Degree of protection Panel-mounting (conforms to IP20)
Material PC/ABS resin
Weight Approx. 300 g
Mounting method DIN Track or M4 screws
Antennas V680-CA5D01-V2:1ch V680-CA5D02-V2:2ch
