DIMM and eUSB Locations in a CMIOU
No. Description Links
This component is part of the power module.
Top to bottom: AC9–AC6
3
Fan modules (36), left to right: FM0–FM5 per switch
unit
“Servicing Fan Modules (Switch
Chassis)” on page 183
4
Switch units (6), top to bottom: SWU_5–SWU_0
“Servicing Switch Units” on page 189
5
SPs (2), left to right: SP0,SP1
“Servicing SPs” on page 117
6
PDECBs (6), top to bottom: PDECB13–PDECB8
“Servicing PDECBs” on page 199
7 SP tray (1) “Servicing SP Trays” on page 243
Related Information
■
“Switch Chassis Front Components (SPARC M7-16)” on page 23
DIMM and eUSB Locations in a CMIOU
DIMMs and a single eUSB disk are located in each of the CMIOUs.
This figure shows a CMIOU with all of the DIMM slots populated with DIMMs. All of
the DIMM slots must be populated with the same size and type of DIMMs. For DIMM
configuration guidelines, see “DIMM Configuration” on page 106.
Identifying Components 27
