Specifications
Main unit
Model No. TH-75BQE1W
Type Touch screen LCD display
Power source 110‒240V~(110‒240Valternatingcurrent),50/60Hz
Power consumption
370 W
Power off with the Main power switch: approx. 0 W
Power off with the remote control: approx. 0.5 W
LCD display panel
VA panel (Direct LED backlight)
75-inch model (16:9 aspect ratio)
Screen size
1 650 mm (W) × 928 mm (H) × 1 893 mm (diagonal) /
64.9” (W) × 36.5” (H) × 74.5” (diagonal)
Number of pixels 8 294 400 pixels (3 840 (horizontal) × 2 160 (vertical))
Operating condition Temperature:0°C‒40°C(32°F‒104°F)
*
1
 Humidity:20%‒80%(nocondensation)
Storing condition Temperature:-20°C‒60°C(-4°F‒140°F)   Humidity:20%‒80%(nocondensation)
HDMI input terminal
TYPE A Connector
*
2
× 2
Audio signal: Linear PCM (sampling frequencies - 48 kHz, 44.1 kHz, 32 kHz)
HDMI 1 / HDMI 2
Digital RGB input
terminal
DVI-D 24 Pin × 1
DVI-D IN
PC input terminal Mini D-sub 15 Pin (Compatible with DDC2B) × 1
PC IN
R/G/B
HD/VD
0.7Vp-p(75Ω)(withoutsyncsignal)
TTL
Audio input terminal
Stereo mini jack (M3) × 1, 0.5 Vrms, shared with DVI-D IN and PC IN
AUDIO IN
Audio output terminal Stereo mini jack (M3) × 1, 0.5 Vrms
AUDIO OUT Output:Variable(-∞‒0dB)(1kHz0dBinput,10kΩload)
Serial input terminal
External Control Terminal
D-sub 9 Pin × 1 RS-232C compatible
SERIAL IN
External speaker
terminal
8Ω,20W[10W+10W](10%THD)
EXT SP
IR input terminal
Stereo mini jack (M3) × 1
IR IN
USB flash drive
terminal
TYPE A USB connector × 1
DC 5V / 1A (USB 3.0 is not supported.)
USB
Outer dimensions
(W × H × D)
1 710 mm × 989 mm × 102 mm / 67.3” × 39.0” × 4.02”
1 710 mm × 1 072 mm × 102 mm / 67.3” × 42.3” × 4.02” (horizontal installation /
when the speaker mounted)
989 mm × 1 793 mm × 102 mm / 39.0” × 70.6” × 4.02” (vertical installation /
when the speaker mounted)
Mass Approx. 66.0
/ 145.5 lbs (Approx. 68.0 / 150.0 lbs when the speaker mounted.)
Cabinet material Front: metal / Back cover: metal
