USER MANUAL PANDORA ELITE V2
Base unit
Built-in GSM modem (2G/3G/4G LTE) provides a connection with our online-service pandora-on.
com and mobile applications (Pandora Online/Pandora Pro), allows to control the system by a phone
using DTMF-commands, voice and SMS notifications, automatic date and time detection. The modem
operates in a mobile network using the built-in SIM-chip or/and a nano-SIM.
Built-in SIM-chip is and integrated SIM-card chip that it used to work with the built-in GSM modem.
The built-in SIM-chip has a tariff plan for Russia (phone number is written on the “Owner’s personal
card”).
Built-in slot for a nano-SIM is used for owner’s SIM-card (nano-SIM). If both the SIM-chip and SIM-
card are used in the system, there is a function that allows to automatically switch between the SIM-chip
and the SIM-card if there is no internet connection.
!
It Is RequIRed to INstAll AN AddItIoNAl sIm-cARd IN the NANo-sIm slot foR the AutomAtIc mode.
Built-in GPS/GLONASS-receiver is designed to determine current location and to automatically
determine UTS date and time.
2.4GHz radio channel, Bluetooth 5.0 protocol (BT5.0) - supports up to 14 additional Bluetooth
devices (see the “Additional devices” section), including a mobile phone.
Built-in 3D accelerometer is used to detect shock/motion/tilt including 2 separate zones of shock
sensor (alarm and warning), the system allows to adjust sensitivity of each zone, to use data from the
accelerometer to block the engine and close the central lock on movement.
Temperature sensors allow the system to measure temperature of different zones to send
this information to the remote control or mobile apps. The following zones are available: interior
temperature – built in sensor of the main unit, engine temperature – external temperature sensor (see
the “System set”), outside temperature – digital car protocol*
The system setting allow you to reassign sensor to different zones and use information from external
additional devices (PS-331BT, RHM-03 BT, DMS-100 BT); to implement automatic engine or engine pre-
heater starts and stops by temperature.
Emergency power – the system has an input for an external back-up battery in order to notify an
owner in case of power disconnection in armed mode. The battery will be charged automatically when
engine is running.
Built-in digital 3хCAN/2xLIN* interface allows the system to read status end exucute commands
via digital buses, and work with Webasto Thermo Top Evo Eberspacher Hydronic/2.
Built-in digital IMMO-KEYport and immobilzer bypass* – hardware and software algortihms
with the special Pandora CLONE server allow the system to bypass original immobilizers for automatic
and remote engine starts.
Built-in micro-USB port – update and configuration of the system using a PC and Pandora Alarm
Studio.
! *moRe INfoRmAtIoN Is AvAIlAble oN loAdeR.pANdoRAINfo.com
RF-module RFМ-470 is an external antenna that provides wireless
communication between the system and remote controls.
868MHz Antenna, LoRa modulation supports up to 4 remote controls
D-043 LoRa, D-022 LoRa.
2.4GHz Antenna, Bluetooth 4.2 protocol provides connection between
the base unit and the RF-module.
CALL button is an integrated button. Press and hold the button for 1
second or more, the remote control will indicate “CALL”.
Piezo siren PS-332 BT is a wireless device for sound indication:
Control connection with the base unit
souNd pRessuRe 118 db | 2.4Ghz (ble 4.2) RAdIo INteRfAce
2,4 GHz
Antenna
