Chapter 3: Starting Your PowerStation PowerStation Connectors
PA PowerStation User Guide 3-3
Settings and Pinouts for COM1
If you need to make a cable for communicating with COM1, Table 3-1
shows the pinouts and signal information for this port.
Table 3-1: COM1 Pinouts
Dip Switch Settings and Pinouts for COM2 on the 5”, 6”, 8”, and 10” Units
If you need to make a cable for communicating with COM2 on a 5”, 6”, 8”
and 10” unit, Table 3-2, shows the pinouts and signal information for this
port.
Table 3-2: COM2 Pinouts on 5”, 6”, 8”, and 10” Units
Caution: Note that RTS and CTS signals are not active in RS-422 and RS-
485 configurations.
Pin# Signal
1 DCD, data carrier detect
2RXD, received data
3 TXD, transmitted data
4 DTR, data terminal ready
5 Signal ground
6DSR
7 RTS, request to send
8 CTS, clear to send
9RI
Pin#
RS-232
Communication
RS-422
Communication
RS-485
Communication
1 DCD, data carrier
detect
TXD-, transmitted
data -
TXD-, transmitted
data -
2 RXD, received data TXD+, transmitted
data +
TXD+, transmitted
data +
3 TXD, transmitted
data
RXD+, received data
+
RXD+, received data
+
4 DTR, data terminal
ready
RXD-, received data
-
RXD-, received data
-
5 Signal ground Signal ground Signal ground
6 DSR, data set ready DSR, data set ready DSR, data set ready
7 RTS, request to send RTS, request to send RTS, request to send
8 CTS, clear to send CTS, clear to send CTS, clear to send
9RIRIRI
