Appendix A : PowerStation Specifications Physical Specifications
PA PowerStation User Guide A -2
Physical Specifications
Physical specifications include the PowerStation’s CPU, memory
specifications, display types, storage capacity, and other physical
characteristics. These specifications are shown in Table A-1, below.
Table A-1: Physical Specifications
Category PA05/PA06/PA08/PA10 Units PA15 Units
Operating
System
ROM-DOS 6.11 ROM-DOS 6.11
CPU
• 200MHz X86 instruction set compatible
processor
• 500MHz X86 instruction set compatible
processor
Memory
• Up to 1 GB DDR SDRAM Maximum
• 32MB PC100/PC133 SDRAM
• 144-pin SODIMM Socket
• Up to 1 GB DDR SDRAM Maximum
• 128MB PC3200 DDR
• 200-pin SODIMM Socket
BIOS
• Award 256KB Flash • Insyde XpressROM
Storage
• 128MB - 8G CompactFlash card
• Supports Type 1 and 2 CompactFlash
cards
• 128MB - 8G CompactFlash card
• Supports Type 1 and 2 CompactFlash
cards
I/O Ports
• Two 9-pin serial ports (16550 compat-
ible)
• 1 RS232
• 1 RS232/422/485 (configurable)
• One RJ45 Ethernet connector;
Intel 82551ER 10/100 Base-T
controller
• Two 9-pin serial ports (16550 compat-
ible)
• 1 RS232
• 1 RS232/422/485 (configurable)
• One RJ45 Ethernet connector;
Intel 82551ER 10/100 Base-T
controller
Dimensions
H x W x D
For the 5” and 6”:
• 6.0”H x 7.4”W x 2.3”D
For the 8”:
• 7.6”H x 10.2”W x 2.2”D
For the 10”:
• 11.0”H x 13.8”W x 3.2”D
• 13.3”H x 16.8”W x 4.6”D
Weight For the 5” and 6”:
• 2.1 lbs/0.95 kgs
For the 8”:
• 4.1 lbs/1.86 kgs
For the 10”:
• 8.4 lbs/ 3.81kgs
For the 15”:
• 13.8 lbs/6.26 kgs
Keyboard
• 1 PS/2 miniDIN • USB keyboard only
Mouse
• 1 PS/2 miniDIN • USB mouse only
Touchscreen
• Analog Resistive • Analog Resistive
Audible
• Piezoelectric Beeper • Piezoelectric Beeper
