23 GB/IE/NI
will not turn on under “LASER LINE”
mode.
Use
Tip for distance
measurement
In order to avoid measuring errors, please
note the following information (see fig. C):
The measurement is performed by laser,
which travels from the laser sender
15
.
The laser is reflected from the target area
and received by the laser receiver
16
.
The product calculates the measured length
from the travel time of the laser signal.
In order to guarantee an exact measure-
ment, the following conditions should be
maintained:
- Make sure that the product is always
directed at a right angle towards a flat
surfaced wall.
- The measuring distance range should
not exceed 0.175 m to 20 m.
-
Ensure that there are no objects positioned
within the measurement area, which could
reflect the laser prematurely.
