01_07
Light switch (01_07)
Button light switch «L»
0 = Low-beam and taillight
1 = High-beam and taillight
2 = High-beam flash (passing)
CAUTION
DO NOT PLACE, TRANSPORT OBJECTS AND/OR CLOTHES OVER THE FRONT
HEADLIGHT ASSEMBLY, WHEN THE HEADLIGHT IS TURNED ON OR OFF.
FAILURE TO FOLLOW THIS PRECAUTION MAY CAUSE OVERHEATING AND
THE SUBSEQUENT FUSION OF THE GLASS.
01_08
Start-up button (01_08)
To start the engine, press the starter button, «P», after pulling either one of the two
brake levers.
The immobilizer system
In order to enhance theft protection, the vehicle is equipped with a «PIAGGIO IMMO-
BILIZER » electronic engine locking device that is activated automatically when the
ignition key is removed. Upon start-up, the «PIAGGIO IMMOBILIZER» system checks
14
