TYRES MUST BE REPLACED WHEN THE TREAD REACHES THE WEAR LIMITS
SET FORTH BY LAW.
TYRE PRESSURE
Front tyre pressure 2 bar
Rear tyre pressure 2.2 bar
Rear wheel tyre pressure (at full
load)
2.5 bar
TYRES
Front tyre Tubeless, 80/90 - 15" 51J
Rear tyre Tubeless, 100/80 - 14" 54J
03_06
Spark plug dismantlement (03_06, 03_07)
In order to inspect the spark plug, follow the operation described when the engine is
cold:
1. Remove cover «B» after unscrewing the corresponding screws «A»;
2. Detach the spark plug cap «C»;
3. Remove the spark plug with the supplied spanner (with retaining rubber).
39
