Maximum weight allowed 300 kg
Battery Sealed, 12 V / 6 Ah
CAPACITIES
Engine oil quantity 1,340 cm³ (of which 120 cm³ in the
filtering cartridge)
Hub oil quantity 300 cm³
Fuel tank capacity ~ 6.5 ± 0.5 litres (of which 1.5 l is
reserve)
04_02
Tool kit (04_02)
The toolkit includes:
1. Box-spanner to extract the spark plug;
2. Twin screwdriver;
3. An open spanner (13 mm);
4. A wrench to adjust shock absorber.
5. Torx wrench
The toolkit plastic pouch is fastened to the saddle with a clamp. To take it out, just
push the tabs at the same time you loosen the clamp.
68
