03_30
Inactivity of the vehicle (03_30)
The following operations are recommended:
1 - General cleaning of the vehicle
2 - With the engine off and the piston at bottom dead centre position, remove the spark
plug and pour 1÷2 cm³ of motor oil through its hole. Operate the starter motor 3-4 times
letting the engine perform a few revolutions, then remount the spark plug.
3 - Drain up all the vehicle's fuel; spread antirust grease on the uncoated metal parts;
keep the wheels lifted above the ground.
4 - For the battery, follow the procedures described in the «Battery» section.
5 - Replace engine oil.
Recommended products
eni i-Ride PG 5W-40
Synthetic based lubricant for high-performance four-stroke engines.
JASO MA, MA2 - API SL - ACEA A3
Cleaning the vehicle (03_31)
Use a low pressure jet of water to soften the caked dirt and mud deposited on the
painted surfaces. Once softened, sponge off mud and dirt using a car body sponge
soaked in a car body shampoo and water solution (2-4% of car shampoo in water).
Then rinse with abundant water, and dry with a shammy cloth. For the engine exterior,
use petrol, a brush and clean cloths. Petrol can damage paintwork. Remember that
any polishing with silicone wax must always be preceded by washing.
57
3 Maintenance
