Pioneer A-40AE User Manual

23
Others
En
Rated Output Power (IEC)
2 ch k 76 W at 4 ohms, 1 kHz, 2 ch driven of 0.9% THD
2 ch k 52 W at 8 ohms, 1 kHz, 2 ch driven of 0.9% THD
Input Sensitivity and Impedance
200 mV/47 k≠ (LINE (RCA))
4 mV/47 k≠ (PHONO MM)
Phono Maximum Input Signal Voltage
70 mV (MM 1 kHz, 0.5%)
Frequency Response
10 Hz - 100 kHz/i1 dB, j3 dB (DIRECT)
Tone Control Characteristics
n10 dB, 100 Hz (BASS)
n10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio
106 dB (IHF-A, LINE IN, SP OUT)
81 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
A, B: 4 ≠ - 16 ≠
A+ B: 8 ≠ - 32 ≠
Bi-wiring: 4 ≠ - 16 ≠
Supported impedance of Headphones
8 ≠ - 600 ≠
Headphones Frequency Response
30 Hz -100 kHz
Power Supply
AC 220-230 V, 50/60 Hz
Power Consumption
150 W
0.2 W (Stand-by)
Dimensions (W k H k D)
435 mm k 129 mm k 323 mm
17-1/8" k 5-1/16" k 12-11/16"
Weight
8.2 kg (18.1 lbs)
Digital
OPTICAL
Maximum Fs: 192 kHz
COAXIAL
Maximum Fs: 192 kHz
Analog
PHONO, CD/SACD, LINE1, LINE2, LINE3, LINE4, P.AMP
DIRECT
Analog
LINE OUT L/R
Speaker Outputs
SPEAKERS A: L/R
SPEAKERS B: L/R
Phones
PHONES (Ø6.3 mm)
CONTROL IN: 1
CONTROL OUT: 1
Specifications
Amplifier (Audio) section
General
Audio Inputs
Audio Outputs
Others
SN29403415_A-40AE_En_1804XX.book 23 ページ ２０１８年５月２３日 水曜日 午後３時１９分

Pioneer A-40AE Specifications

General

Purpose	-
Material	Aluminium, Steel
Product color	Black
Volume control	Rotary
Bass adjustment	Yes
Connectivity technology	Wired
Frequency range	10 - 100000 Hz
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	- %
Built-in display	No
Digital audio optical in	1
AC input voltage	220 - 230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	150 W

Weight and Dimensions

Depth	323 mm
Width	435 mm
Height	129 mm
Weight	8200 g
