List of MIDI Messages
On this unit, the browser, deck, mixer and effect sections are connected with the MIDI channels shown below.
Deck A MIDI channel 0
Deck B MIDI channel 1
Deck C MIDI channel 2
Deck D MIDI channel 3
Effect 1 MIDI channel 4
Effect 2 MIDI channel 5
Browser, mixer MIDI channel 6
1 Browser
SW Name
MIDI message (this unit to
computer)
Notes
TREE button 96 66 dd OFF=0, ON=127
Rotary selector (turn) B6 64 dd
Difference count value from when previously operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
Rotary selector (press) 96 65 dd OFF=0, ON=127
FAVORITES (REC) button 96 67 dd OFF=0, ON=127
LOAD A button 96 70 dd OFF=0, ON=127
LOAD B button 96 71 dd OFF=0, ON=127
LOAD C button 96 72 dd OFF=0, ON=127
LOAD D button 96 73 dd OFF=0, ON=127
2 Deck
SW Name
MIDI message (this unit to computer)
Notes
When SHIFT button is off When SHIFT button is on
PLAY/
PAUSE f button
9n 11 dd 9n 71 dd OFF=0, ON=127
CUE button 9n 12 dd 9n 72 dd OFF=0, ON=127
AUTO LOOP (MOVE GRID) control (turn) Bn 19 dd Bn 79 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
AUTO LOOP (MOVE GRID) control (press) 9n 20 dd 9n 80 dd OFF=0, ON=127
IN (IN ADJUST) button 9n 16 dd 9n 76 dd OFF=0, ON=127
OUT (OUT ADJUST) button 9n 17 dd 9n 77 dd OFF=0, ON=127
ACTIVE button 9n 18 dd 9n 78 dd OFF=0, ON=127
FUNCTION button 9n 58 dd 9n 107 dd OFF=0, ON=127
NEEDLE SEARCH pad Bn 3 dd Bn 8 dd
OFF = 0, ON = 1–127 (position information)
1 at left edge, 27 at right edge
Filter control Bn 4 dd Bn 9 dd 0-127
FILTER button 9n 69 dd 9n 116 dd OFF=0, ON=127
MOVE/
HOT CUE selector button 9n 42 dd 9n 91 dd OFF=0, ON=127
MODE DELETE button 9n 45 dd 9n 94 dd OFF=0, ON=127
SIZE c button, 1 button, 5 button
9n 46 dd 9n 95 dd OFF=0, ON=127
SIZE d button, 2 button, 6 button
9n 47 dd 9n 96 dd OFF=0, ON=127
c BWD button, 3 button, 7 button
9n 48 dd 9n 97 dd OFF=0, ON=127
FWD d button, 4 button, 8 button
9n 49 dd 9n 98 dd OFF=0, ON=127
KEY LOCK button 9n 26 dd 9n 86 dd OFF=0, ON=127
TEMPO RANGE button 9n 25 dd 9n 85 dd OFF=0, ON=127
TEMPO slider
Bn
Bn
0
32
MSB
LSB
Bn
Bn
5
37
MSB
LSB
0–16383
0 at – side, 16383 at + side
