Pioneer DJM-800 Service Manual

DJM-800
116
1234
1234
C
D
F
A
B
E
5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
MarkNo. Description Part No.
LIST OF ASSEMBLIES
NSP 1..INFD ASSY DWM2239
2..INPUT ASSY DWX2535
2..MIC 1 ASSY DWX2542
2..MIC 2 ASSY DWX2543
2..SLSW ASSY DWX2536
2..CHFD 1 ASSY DWX2537
2..CHFD 2 ASSY DWX2538
2..CHFD 3 ASSY DWX2539
2..CHFD 4 ASSY DWX2540
2..CRSFD ASSY DWX2541
NSP 1..OUDIG ASSY DWM2240
2..OUTPUT ASSY DWX2544
2..AC SW ASSY DWX2545
2..DIGIB ASSY DWX2546
2..DIGIC ASSY DWX2547
2..TRIM 1 ASSY DWX2548
2..TRIM 2 ASSY DWX2549
2..TRIM 3 ASSY DWX2550
2..TRIM 4 ASSY DWX2551
NSP 1....PANEL-A ASSY DWM2241
2..PANEL 1 ASSY DWX2552
2..HPJACK ASSY DWX2553
NSP 1....PANEL-B ASSY DWM2242
2..PANEL 2 ASSY DWX2554
2..DIGI A ASSY DWX2555
1..DSP ASSY DWX2534
1..HPAMP ASSY DWX2556
> 1..POWER SUPPLY UNIT DWR1433
Mark No. Description Part No.
A
INPUT ASSY
SEMICONDUCTORS
IC409, IC509, IC609, IC709 CS5361-KS
>
IC809, IC810 DEK1096
IC405, IC505, IC605, IC705 LM4040EIM3-2.5
IC501, IC601, IC701 NE5532AD
IC401–IC404, IC406, IC502–IC504 NJM4580MD
IC506, IC602–IC604, IC606 NJM4580MD
IC702–IC704, IC706, IC801, IC802 NJM4580MD
IC804 NJM4580MD
IC803 PCM1742KE
IC805 TA78L12F
IC451–IC456, IC806, IC807 TC7SH08FUS1
IC408, IC508, IC608, IC708 TC7WH157FU
Q801–Q808 2SC3326
Q504–Q507, Q604–Q607 2SK371D1
Q704–Q707 2SK371D1
Q401, Q501, Q601, Q701 DTC124EUA
D410, D411, D510, D511 1SS355
D610, D611, D710, D711 1SS355
D401–D404, D501–D504 RB706D-40
D601–D604, D701–D704 RB706D-40
D409, D509, D609, D709 UDZS5R6(B)
COILS AND FILTERS
L803 LCKAW221J2520
F489–F492, F589–F592 VTF1093
F689–F692, F789–F792 VTF1093
SWITCHES AND RELAYS
RY401, RY501, RY601, RY701 VSR1008
CAPACITORS
C403–C406, C421–C424, C435 CCSRCH101J50
C440, C444, C445, C449, C450 CCSRCH101J50
C521–C524, C535, C540 CCSRCH101J50
C544, C545, C549, C550 CCSRCH101J50
C621–C624, C635, C640 CCSRCH101J50
C644, C645, C649, C650 CCSRCH101J50
C721–C724, C735, C740 CCSRCH101J50
C744, C745, C749, C750 CCSRCH101J50
C571, C572, C671, C672 CCSRCH181J50
C771, C772 CCSRCH181J50
C503, C504, C603, C604 CCSRCH221J50
C703, C704 CCSRCH221J50
C509, C510, C609, C610 CCSRCH331J50
C709, C710 CCSRCH331J50
C573, C574, C673, C674 CCSRCH471J50
C773, C774 CCSRCH471J50
C465, C565, C665, C765 CEHAR100M16
C419, C420, C429, C430, C464 CEHAR100M35
C488–C490, C497, C519, C520 CEHAR100M35
C529, C530, C564, C566, C567 CEHAR100M35
C588, C589, C619, C620 CEHAR100M35
C629, C630, C664, C666, C667 CEHAR100M35
C688, C689, C699, C719, C720 CEHAR100M35
C729, C730, C764, C766, C767 CEHAR100M35
C788, C789, C809–C812 CEHAR100M35
C817–C820, C823, C826, C836 CEHAR100M35
Mark No. Description Part No.
