Pioneer DJM-800 Service Manual

DJM-800
174
1234
1234
C
D
F
A
B
E
9.3 SCHEMATIC DIAGAM
CN1
C
CN3 &
C
CN2
C
CN4 &
C
1
1
Connector Ass'y (W)
Connector Ass'y (Y)
Solder
Solder
Potentiometer
Potentiometer
White
White
Yellow
White
Gray
Gray
Note: Although the ref. numbers for the CH1/CH3 FADER Assys are
different, they are identical, and their functions in the circuitry are the
same. You can connect to either of them.
Note: Although the ref. numbers for the CH2/CH4 FADER Assys are
different, they are identical, and their functions in the circuitry are the
same. You can connect to either of them.

Pioneer DJM-800 Specifications

General

Equalizer	Yes
Product color	Black
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.005 %
Connectivity technology	Wired
Digital audio coaxial out	1
Dimensions (WxDxH)	320 x 108 x 381 mm
Power consumption (typical)	30 W

Weight and Dimensions

Weight	8000 g
