Pioneer DJM-800 Service Manual

DJM-800
123
5678
56
7
8
C
D
F
A
B
E
6. ADJUSTMENT
• There is no information to be shown in this chapter.
C2532 CEAT470M25
C2502–C2505, C2508, C2538, C2539 CKSRYB104K25
C2506, C2507, C2509 CKSRYB104K50
RESISTORS
R2501, R2513, R2515, R2532 RD1/2VM122J
R2518, R2523 RD1/2VM221J
R2504, R2524 RN1/16SE1001D
R2509, R2528 RN1/16SE1802D
R2516, R2519, R2533, R2535 RS2LMF270J
Other Resistors RS1/16S###J
OTHERS
CN2501 KR CONNECTOR B4B-PH-K
CN2502 5P TOP POST B5B-EH
CN2503 16P FFC CONNECTOR DKN1453
P
HPJACK ASSY
COILS AND FILTERS
F802–F804 VTF1093
CAPACITORS
C809, C810 CKSRYB104K25
RESISTORS
Other Resistors RS1/16S###J
OTHERS
CN9 KR CONNECTOR B4B-PH-K
JA10 HEADPHONE JACK DKN1281
R
ACSW ASSY
SWITCHES AND RELAYS
>
S1 DSA1031
CAPACITORS
>
C1 ACG7030
OTHERS
>
CN91 AMP U-P CONNECTOR 2P 2-178496-4
>
J0 CONNECTOR ASSY DKP3768
Mark No. Description Part No.

Pioneer DJM-800 Specifications

General

Equalizer	Yes
Product color	Black
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.005 %
Connectivity technology	Wired
Digital audio coaxial out	1
Dimensions (WxDxH)	320 x 108 x 381 mm
Power consumption (typical)	30 W

Weight and Dimensions

Weight	8000 g
