Pioneer DJM-800 Service Manual

DJM-800
6
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING SECTION
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
5
11
12
9
4
3
7
DJM-800
6
10
2
8
FRONT

Pioneer DJM-800 Specifications

General

Equalizer	Yes
Product color	Black
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.005 %
Connectivity technology	Wired
Digital audio coaxial out	1
Dimensions (WxDxH)	320 x 108 x 381 mm
Power consumption (typical)	30 W

Weight and Dimensions

Weight	8000 g
