Pioneer DJM-800 Service Manual

DJM-800
28
1234
1234
C
D
F
A
B
E
3.9 INPUT ASSY (6/6)
LRCK BUFFER
BCK BUFFER
(CH1Y)
(CH2Y)
(CH3Y)
(CH4Y)
: CH 1 Y CH SIGNAL
: CH 2 Y CH SIGNAL
: CH 3 Y CH SIGNAL
: CH 4 Y CH SIGNAL
: CH1 DIGITAL SIGNAL
: CH2 DIGITAL SIGNAL
: CH3 DIGITAL SIGNAL
: CH4 DIGITAL SIGNAL
: MASTER L CH SIGNAL
(CH1Y)
(CH4Y)
(CH2Y)
(D1)
(D2)
(D3)
(D4)
(MA)
(CH3Y)
AUDIO SIGNAL ROUTE
24
28
27
26
25
A 6/6
INPUT ASSY (DWX2535)
A 6/6
1/3
CN3
I
1/3
CN2
I
5/6
A
1/6A
1/6,2/6,3/6,4/6
A
2/6A
3/6A
4/6A
5/6A

Pioneer DJM-800 Specifications

General

Equalizer	Yes
Product color	Black
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.005 %
Connectivity technology	Wired
Digital audio coaxial out	1
Dimensions (WxDxH)	320 x 108 x 381 mm
Power consumption (typical)	30 W

Weight and Dimensions

Weight	8000 g
