Pioneer SC-LX85 User Manual

115
En
14
Additional information
Specifications
Audio Section
Multi channel simultaneous power output
(1 kHz, 1 %, 8 W)
9 ch total
................810 W (SC-LX85)/720 W (SC-LX75)
Rated power output (1 kHz, 6 W, 1 %)
Front .................... 190 W + 190 W (SC-LX85)
180 W + 180 W (SC-LX75)
Center ..................................190 W (SC-LX85)
180 W (SC-LX75)
Surround ............. 190 W + 190 W (SC-LX85)
180 W + 180 W (SC-LX75)
Surround back .... 190 W + 190 W (SC-LX85)
180 W + 180 W (SC-LX75)
Front height/Front wide
............................. 190 W + 190 W (SC-LX85)
180 W + 180 W (SC-LX75)
Rated power output
(1 kHz, 8 W, 0.08 %)
Front ..................................... 140 W + 140 W
Center ...................................................140 W
Surround .............................. 140 W + 140 W
Surround back ..................... 140 W + 140 W
Front height/Front wide ....... 140 W + 140 W
Total harmonic distortion .......................... 0.04 %
(1 kHz, 130 W + 130 W, 8 W)
Guaranteed speaker impedance ....... 6 W to 16 W
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE .....................................................103 dB
Input (Sensitivity/Impedance)
PHONO MM ................................ 5 mV/47 kW
LINE .........................................400 mV/47 kW
Output (Level/Impedance)
REC ......................................... 380 mV/2.2 kW
Tuner Section
Frequency Range (FM) ......87.5 MHz to 108 MHz
Antenna Input (FM) .................. 75 W unbalanced
Frequency Range (AM) ........ 531 kHz to 1602 kHz
Antenna (AM) .............. Loop antenna (balanced)
Video Section
Signal level
Composite Video ....................... 1 Vp-p (75 W)
Component Video .............Y: 1.0 Vp-p (75 W),
PB/PR: 0.7 Vp-p (75 W)
Corresponding maximum resolution
Component Video ...................1080p (1125p)
(Video convert off)
Digital In/Out Section
HDMI terminal ............................19-pin (Not DVI)
HDMI output type .................................5 V, 55 mA
USB terminal ............USB2.0 Full Speed (Type A)
iPod terminal ......... USB, and Video (Composite)
ADAPTER PORT terminal ..................5 V, 100 mA
WIRELESS LAN ADAPTER terminal
.............................................................5 V, 600 mA
Integrated Control Section
Control (SR) terminal ..... ø 3.5 Mini-jack (MONO)
Control (IR) terminal ......ø 3.5 Mini-jack (MONO)
IR signal ............... High Active (High Level: 2.0 V)
12 V Trigger terminal ......ø 3.5 Mini-jack (MONO)
12 V Trigger output type ..........12 V, Total 150 mA
RS-232C cable type ...................9-pin, cross type,
female-female
SC-LX85 only:
CU-RF100 terminal .............................5 V, 150 mA
SC-LX75 only:
EXTENSION terminal .........................5 V, 150 mA
Network Section
LAN terminal .................10 BASE-T/100 BASE-TX
Miscellaneous
Power requirements
............................. AC 220 V to 230 V, 50 Hz/60 Hz
Power consumption ....................................370 W
In standby .............................................. 0.1 W
(HDMI Setup – Control : OFF)
.............. 0.3 W (HDMI Setup – Control : ON)
Dimensions
....... 435 mm (W) x 185.6 mm (H) x 440.3 mm (D)
Weight (without package)
SC-LX85 .............................................. 17.9 kg
SC-LX75 .............................................. 17.6 kg
Number of Furnished Parts
In case of SC-LX85
MCACC Setup microphone ................................ 1
Omni-directionalremote control (CU-RF100) .... 1
RF adapter ........................................................... 1
IR blaster cable ................................................... 2
AA/LR6 dry cell batteries .................................... 4
iPod cable ............................................................ 1
Wireless LAN converter (AS-WL300) ................. 1
AM loop antenna ................................................. 1
FM wire antenna ................................................. 1
Warranty card...................................................... 1
Power cord
CD-ROM (AVNavigator)
Quick start guide
In case of SC-LX75
MCACC Setup microphone ................................ 1
Remote control unit ............................................ 1
AAA size IEC R03 dry cell batteries .................... 2
iPod cable ............................................................ 1
Wireless LAN converter (AS-WL300) ................. 1
AM loop antenna ................................................. 1
FM wire antenna ................................................. 1
Warranty card...................................................... 1
Power cord
CD-ROM (AVNavigator)
Quick start guide
Note
! These specifications are applicable when the
power supply is 230 V.
! Specifications and the design are subject to
possible modifications without notice, due to
improvements.
! This product includes FontAvenue
®
fonts
licensed by NEC Corporation. FontAvenue is a
registered trademark of NEC Corporation.

Pioneer SC-LX85 Specifications

General

Frequency range	5 - 100000 Hz
Output impedance	6 Ω
Input sensitivity	400 mV
Audio output channels	9.2 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	103 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Digital audio coaxial in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
Wi-Fi	-
Supported radio bands	AM, FM
Preset stations quantity	63
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD, THX Surround EX
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
THX-certified	THX

Weight and Dimensions

Depth	442 mm
Width	435 mm
Height	185 mm
